Identification check
Confirm the supplied reference, the product family and visible construction before advancing the inquiry.
Fasteners & Hardware · Keys & Locking Hardware
240-1556 (2401556) Pin Retainer Plate for Caterpillar D6K, D6K2 and PL61
Primary part referenceSubmit your reference for matching
1 / 2
Fasteners & Hardware · Keys & Locking Hardware
240-1556 (2401556) Pin Retainer Plate for Caterpillar D6K, D6K2 and PL61
Pin retainer plate referenced as 240-1556 for the power-angling C-frame lift pin. Reference specifications list a 20 mm nominal thickness, 46 mm hole-center distance and two mounting holes. Confirm the equipment serial number and current blade or C-frame configuration before ordering.
Primary part reference
Submit your reference for matching
- Additional references
- Cross-reference, stamping or drawing number when available
- System category
- Fasteners & Hardware
- Product type
- Keys & Locking Hardware
- Family
- Locking Plates & Tabs
- Compatibility
- Confirm with your machine or engine details
Product description
Understand the 240-1556 Pin Retainer Plate
Review the 240-1556 identity, its pin retainer plate for the power-angling c-frame lift pin and the supported application boundary before comparing it with the existing component.
Pin retainer plate referenced as 240-1556 for the power-angling C-frame lift pin. Reference specifications list a 20 mm nominal thickness, 46 mm hole-center distance and two mounting holes. Confirm the equipment serial number and current blade or C-frame configuration before ordering.
Identify the 240-1556 Reference
Use the complete part number together with the visible product form and current equipment records when comparing this pin retainer plate.
Review the Product Details
- Pin retainer plate for the power-angling C-frame lift pin
- 20 mm nominal reference thickness
- 46 mm reference hole-center distance
- Two-hole plate form
Confirm the Application
Application reference: selected Caterpillar D6K, D6K2 and PL61 configurations using the power-angling C-frame lift pin. Confirm equipment serial number and current blade or C-frame arrangement before quotation.
Send the Details Needed for a Quote
Send the complete part number, equipment serial number and current blade or C-frame arrangement, clear photographs of the existing part and the required quantity for a focused review.
Product specifications
Product information for matching 240-1556 Pin Retainer Plate
Use the listed specifications together with the supplied reference and application details.
| Reference Material | Hardened steel |
|---|---|
| Nominal Thickness | 20 mm (0.79 in) |
| Hole-Center Distance | 46 mm (1.81 in) |
| Reference Length | 4.57 in |
| Reference Width | 3.35 in |
| Hole Size | 0.71 in, 2X |
Identification notes
Compare the 240-1556 Pin Retainer Plate
Compare the complete part number, the pin retainer plate for the power-angling c-frame lift pin, the 20 mm nominal reference thickness and the gallery views with the existing component.
- Keep the complete part shape and connection points visible
- Photograph both sides when profiles, ports or mounting features differ
- Pair the images with the machine model, serial range or supplied reference
Compatibility applications
Confirm the 240-1556 Application
Verify equipment serial number and current blade or C-frame arrangement before quotation.
Compatibility requires confirmation.
Application reference: selected Caterpillar D6K, D6K2 and PL61 configurations using the power-angling C-frame lift pin. Confirm equipment serial number and current blade or C-frame arrangement before quotation.
Quality context
Reduce Ordering Risk for 240-1556
Use the part number, equipment serial number and current blade or C-frame arrangement and clear photographs together to reduce identification and ordering errors.
Dimensional context
Use approved drawings, marked measurements or sample information wherever the mounting interface requires it.
Requirement alignment
Record operating conditions, material, inspection or documentation requirements in the product RFQ.
Product RFQ
Request a Quote for 240-1556
Send the complete part number, equipment serial number and current blade or C-frame arrangement, existing-part photographs and required quantity for a focused review.
Product included
240-1556 Pin Retainer Plate · Fasteners & Hardware · Keys & Locking Hardware · Locking Plates & Tabs
